10-inch In-vehicle Rugged Tablet for Various Industrial Applications
Powered by Android 13 operating system and equipped with GPS, 4G, BT, etc. modules, VT-10A Pro shows efficency and accuracy in handling multiple tasks even in harsh environments.
Features
 |
Octa-core CPUQualcomm octa-core CPU, Kryo Gold (quad-core high performance, 2.0 GHz)+ Kryo Silver (quad-core low power consumption, 1.8 GHz), which is suitable for multitasking and complex computing scenarios with its high performance and energy efficiency. |
Android 13 OSPowered by Android 13, it ensures consistent, stable, and reliable performance with seamless and efficient operation of applications. |
 |
 |
Real-time CommunicationSupport LTE, HSPA+, dual-band Wi-Fi (2.4GHz/5GHz)and Bluetooth 5.0 LE, covering mainstream wireless protocol. With the four satellite systems of GPS+GLONASS+BDS+Galileo, it can realize quick position at any time and place. |
1200 Nits & Customizable Screen10-inch 1280*800 HD screen with 1200 nits brightness, users can clearly read screen in outdoor strong light environments. Supporting customized glove touch and wet touch screen, well touch response can be achieved whether gloves are worn or the screen is wet. |
 |
 |
Rugged and Reliable DesignFeaturing a 7H hardness touchscreen, the tablet effectively resists scratches and wear. The IK07-rated shell withstands 2.0 Joule mechanical impacts. Comply with IP67 and MIL-STD-810G standards ensures protection against dust, water ingress, and vibration. |
ISO 7637-IIDC8-36V wide voltage power input design. Comply with ISO 7637-II standard transient voltage protection. Withstand up to 174V 350ms vehicle power pulse. |
 |
 |
Rich Extended InterfacesRich extended interfaces including GPIO, RS232, CAN 2.0b (optional dual channel), RJ45, RS485, video input, etc., can be applied to vehicle equipment connection and vehicle control. |
Customized Service (ODM/OEM)Integrate multiple functions, such as NFC, eSIM card and Type-C, more functions can be customized according to different needs. |
 |
Accessories
 |
 |
 |
 |
| Screws & Torx wrench (T8, T20) | USB to Type-C cable (optional) | Power adaptor (optional) | RAM 1.5" Double Ball Mount with Backing Plate (optional) |
Product Video
| Communication | |
| GNSS (NA Version) | GPS/GLONASS/BDS/Galileo/QZSS; Internal Antenna (default); External SMA antenna (optional) |
| Mobile Broadband (NA Version) | LTE FDD: B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B66/B71 |
| LTE-TDD: B41; Internal Antenna; External SMA antenna (optional) | |
| Mobile Broadband (EM Version) | LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 |
| LTE TDD: B38/B39/B40/B41 | |
| WCDMA: B1/B2/B4/B5/B8 | |
| GSM: 850/900/1800/1900 MHz; Internal Antenna (default), External SMA antenna (optional) | |
| WIFI | 802.11a/b/g/n/ac;2.4GHz&5GHz |
| Bluetooth | 2.1 EDR/3.0 HS/4.2 BLE/5.0 LE |
| NFC (optional) | ISO/IEC 14443A, ISO/IEC 14443B PICC mode |
| ISO/IEC 14443A, ISO/IEC 14443B PCD mode designed according to NFC Forum | |
| digital protocol T4T platform and ISO-DEP | |
| FeliCa PCD mode | |
| MIFARE PCD encryption mechanism (MIFARE 1K/4K) | |
| NFC Forum tags T1T, T2T, T3T, T4T and T5T NFCIP-1, NFCIP-2 protocol | |
| NFC Forum certification for P2P, reader and card mode | |
| FeliCa PICC mode | |
| ISO/IEC 15693/ICODE VCD mode | |
| NFC Forum-compliant embedded T4T for NDEF short record | |
