VT-Box

VT-Box

Operating System:
Android 7.1
Storage:
16 GB
Storage Expansion:
Micro SD 64 GB
RAM:
2 GB

VT-Box is a new generation of telematics terminal. With powerful processor and memory, the open Android operating system provides a flexible environment and powerful functions for applicaiton development and integration. With a wealth of wireless and wired vehicle peripheral interfaces, it can act as an "in-vehicle hub" that can easily connect with other on-board devices, accessories, and sensors to support advanced, resource-intensive applications.

Features

Qualcomm CPU and Android OS

Qualcomm CPU and Android OS

Built in Qualcomm quad-core CPU and Android operation system, provide a flexible development environment and application.

Strong and Stable

Compliance with vehicle level vibration, shock, drop, UV testing standard, suitable for harsh environment and off-road applications.

Strong and Stable
Water-proof and Oil-proof

Water-proof and Oil-proof

Compliance with IP67 and IP69K water-proof and dust-proof rating, resistance to most fluids in industrial environment.

GPS High Precision GNSS System

Support U-blox high precision satellite navigation system including GPS, GLONASS, Galileo and Beidou.

GPS High Precision GNSS System
Rich Wireless Communication

Rich Wireless Communication

Configure with high speed wireless system including LTE cellular, WIFI and Bluetooth.



Accessories

External Antenna Extension Cable Power Adaptor
External Antenna Extension Cable Power Adaptor

CPU

Qualcomm Cortex-A7 32-bit Quad-core processor, 1.1GHz

GPU

Adreno 304

Operating System

Android 7.1

RAM

2 GB

Storage

16 GB

Storage Expansion

Micro SD 64 GB

Bluetooth

4.2 BLE

WLAN

IEEE 802.11a/b/g/n; 2.4GHz/5GHz

Mobile Broadband

LTE, HSPA+, UMTS, EDGE, GPRS, GSM (Data and Voice)

GNSS

GPS/GLONASS (optional U-blox)

Interfaces

GPIO x2, ACC x1, Analog input x1

RS232 x1

CANBUS x1

Sensor

Accelerator

Power

DC8-36V (ISO 7637-II compliant)

Physical Dimensions (WxDxH)

133W*118.6H*35D (mm)

Weight

305g

Environment

Drop Test: 1.5 Meters

Vibration Test: MIL-STD-810G

IP Ratings: IP67/69

Salt Fog: 96 Hr

UV Exposure: 500 Hr

Working Temperature: -10°C ~ 70°C (14°F - 158°F)

Storage temperature: -20°C ~ 80°C (-4°F - 176°F)
