VT-10 IMX

VT-10 IMX

Operating System:
Linux Debian 10
Storage:
16 GB eMMC (Default)/64GB (Optional)
Storage Expansion:
Micro SD 256 GB
RAM:
2 GB LPDDR4 (Default)/4GB (optional)
LCD:
10.1 inch HD (1280x800), 1000cd/m² high brightness, sunlight readable

VT-10 IMX is a rugged and reliable vehicle-mounter computer, which is widely used in fleet mangement, advanced farming systems, special industry vehicles, etc. The exremely robust industrial grade hardware ensures perfect usage in various harsh environments. The excellent performance of IMX8 makes all all control simple, Linux open platform Debian 10 provides a flexible environment for development. Lilliput's products can be tailored to meet your final needs in terms of hardware, software, interface, or other functions required.






CPU

NXP i.MX 8M Mini, ARM 4xCortex-A53 1.6GHz

GPU

1x Shader, Vivante GC320, Vivante GCNanoUltra

Operating System

Linux Debian 10

RAM

2 GB LPDDR4 (Default)/4GB (optional)

Storage

16 GB eMMC (Default)/64GB (Optional)

Storage Expansion

Micro SD 256 GB

LCD

10.1 inch HD (1280x800), 1000cd/m² high brightness, sunlight readable

Touchscreen

Multi touch capacitive touchscreen supporting glove and rain mode

Bluetooth

BLE 5.0

WLAN (Optional)

IEEE 802.11a/b/g/n; 2.4GHz/5GHz

Mobile Broadband (Optional)

LTE, HSPA+, UMTS, EDGE, GPRS, GSM (Data and Voice)

GNSS (Optional)

GPS/GLONASS (optional U-blox)

Sound

Build-in 2W speaker

Interfaces

GPIO x2, ACC x1, Analog input x1

RS232 x1

CANBUS x1

Sensors

Ambient light sensor

Power

DC9-36V (ISO 7637-II compliant)

Battery (Optional)

3.7V, 8000mAh Li-ion (Replaceable)

Operating time: about 4.5 (Typical)

Charging time: about 4.5 (Typical)

Environment

Gravity Drop Test: 120cm

Vibration Test: MIL-STD-810G

Dust resistance test: IP6x

Water resistance test: IPx7

Operating Temperature: -10°C ~ 65°C (14°F - 149°F)

Charging Temperature: 0°C ~ 55°C (32°F - 131°F)

I/O Ports

USB2.0 (Type-A)

RS232 x2

ACC

Power

CAMBus x1 (Optional CANBus x2)

GPIO x8

RJ45

RS485 (Optional)

Physical Dimensions (WxDxH)

277W*185H*31.6D (mm)

Weight

1357g (2.99lb)
